GENERAL DESCRIPTION:
The Rotary Volumetric Fillers are used to fill a predetermined (target weight) amount of an ingredient measured by volume rather than weight. Our Rotary Volumetric Fillers have multiple pocket sizes available depending on the ingredients being dispensed. All pocket sizes are expandable for fine tuning to get the correct amount of product every time. Our RVF’s eliminate product give-away caused by manual filling and reduce the amount of headcount on the production lines. Machines can be customized depending on your specific requirements.
The Operation of the filler begins with the bulk product being dumped into the incline hopper, from there the product is conveyed up and metered into the rotary volumetric disc. To make sure the correct amount of product is being dispensed, there are multiple product guides and wipers that ensure the product pockets are full while indexing to the fill position. Machines can be ordered with a tooling /sanitation cart for easy access to changeover parts and easy sanitation of stored parts.
DESIGN FEATURES:
• Sanitary Friendly Open Frame Design
• All Support Structure and Food Contact Surfaces fabricated with AISI304 Stainless Steel
• All Nuts & Bolts are 18-8 Stainless Steel unless otherwise specified.
• All Servo Motors and Cabling are IP65 Certified or better.
• All Plastic is food grade and USDA approved.
• Watershed Enclosure.
